Make and Break

Toolserv uses the AMC RT Torque system. The system is designed for make-up and break-out of all rotary tools and premium connections of casing and tubing in the range from 2 3/8” to 17” OD pipe. Torque capacity is 0 to 65,000 lbs. ft. The machines consist of a fixed Headstock, capable of sizes from 2 3/8” to 17” diameter and a travelling Tailstock, again capable of sizes from 2 3/8” to 17”. The Tailstock can be provided with a hinged “Top opening” feature to assist with the loading of tools safely and efficiently. Both heads feature hydraulically controlled clamp cylinders that can go from 17” down to 3” without the need to change jaws between sizes.

This has proved to be beneficial financially through the lack of “down time”, and beneficial to safety, by eliminating the need to carry out the task of changing jaws. Another feature of our RT unit is the fully floating tail and head stocks option for offset torques. The system operates at a low working pressure. This eliminates the need for high pressure hoses and fittings, which in turn reduces costs to the customer.
